Wouxun - KG-UV8D Plus

Artikelnummer: 34790
Barcode: 6946351703488

NOG NIET VOLLEDIG


Duplex Work Mode and Dual Receiving
It can TX on one area while RX on the other area simultaneously , other, RX on the same or different bands of A&B areas simultaneously.

Cross Band Repeater
Frequency offset and direction programmable in repeater Mode UHF/VHF or VHF/UHF cross-band repeater.

Voice Encryption and Non-Standard CTCSS/DCS
CTCSS or DCS create a secret channel between radios , non-standard ctcss or dcs is stronger version , voice encryption function use password encrypt voice data.

Some Improve Functions
Voice compander , backlight intensity can be adjusted , FM radio can be stored and retrieved 20 sets of frequency , power-on message editable.

Niet op voorraad - Levertijd in overleg
€ 119,95 (99.13 excl. 21% BTW)

Features

Elektrische eigenschappen

  • Frequency step: 5 kHz / 6.25 kHz / 10 kHz / 12.5 kHz / 25 kHz / 50 kHz / 100 kHz /
  • Channels: 999
  • Wide and narrow bandwidth selection: Yes
  • Operating temperature: -20℃ to +40℃

Transmitter

  • Power output (Watts): VHF: 1-5 Watts / UHF: 1-4 Watts

Receiver

  • Audio distortion: ≤5%
  • Audio power output: ≤500 mW
  • Sensitivity (12dB SINAD): 0.25 µV
  • Squelch rejection sensitivity:
  • Squelch sensitivity:
  • Audio response:
  • Co-channel rejection:
  • Performance of amplitude limiter:
  • Adjacent channel selection:
  • Inter modulation:
  • Resistance:
  • Spurious radiation:

Fysieke eigenschappen

  • Length: 62 mm
  • Height: 125 mm
  • Width: 34 mm
  • Weight: 490 gram
  • Antenna connector: SMA female

In de verpakking

  • Transceiver: Yes
  • Battery: Li-Ion 2600 mAh
  • Charger: Desk charger with adapter and 12 V car charger
  • Antenna: Yes
  • Installation manual: English
  • Belt clip: Yes
  • Hand strap: Yes
