Polmar - Galaxy VHF

Artikelnummer: 7100055

Barcode: 8032182535294

The Polmar Galaxy VHF is a dual band transceiver suitable for 144-146 MHz. The Galaxy VHF will be delivered with a 1200 mAh Li-Ion battery pack.

Frequentie bereik: RX/TX: 144-146 MHz

Vandaag verstuurd - Stock: 3

€ 59,96 (49.55 excl. 21% BTW)

Features

• Display: Yes, led backlight
• VOX function: Yes
• Emergency (SOS) function: Yes
• High/low power selection: Yes
• Voice guide: English
• CTCSS codes: 48 groups
• DCS codes: 83 groups
• SQL function: Yes
• Quick-charge: Yes, stop automatically when it's full
• Auto scan function: Yes

Elektrische eigenschappen

• Channels: 99
• Operating temperature: -10 °C to +55 °C

Transmitter

• Power output (Watts): HI: 5 Watts ±1 dB LO: 1 Watts
• Modulation: FM
• Emission current: HI: ≤1.7A LO: ≤0.80A
• Max. frequency deviation: ±5 KHz
• Channel space: 25 KHz

Receiver

• Audio distortion: ≤5%
• Audio power output: ≤500 mW
• Sensitivity (12dB SINAD): ≤0.20 µV
• Squelch sensitivity: ≤0.16 µV
• Inter modulation: 50 dB
• Receiving current: ≤140 mA
• Squelch waiting: Average 35 mA

Fysieke eigenschappen

• Length: 60 mm
• Height: 125 mm
• Width: 35 mm
• Weight: 350 gram
• Antenna connector: SMA male

In de verpakking

• Transceiver: Yes
• Battery: Li-Ion 1200 mAh
• Charger: Desk charger with adapter and 12 V car charger
• Antenna: Yes
• Installation manual: English
• Belt clip: Yes
