Albrecht - AE 6491 VOX Albrecht - AE 6491 VOX Albrecht - AE 6491 VOX Albrecht - AE 6491 VOX

Albrecht - AE 6491 VOX

Artikelnummer: 12648
Fabrieksnummer: 12648.01
Barcode: 4032661264817

An easy to mount automatic 12/24 volt switching mobile CB Radio with front speaker and DIN-size mobile mounting bracket. The latest generation of CB transceivers with multi-coloured wide angle LCD guarantees legibility from every perspective.The three watt front speaker provides a loud, clear sound.

Frequentie bereik: 26.965 - 27.405 MHz
Vandaag verstuurd - Stock: 3
€ 173,95 (143.76 excl. 21% BTW)

Features

  • Modulation: AM / FM
  • Multi-bands: Yes
  • Output power: 4 Watt
  • Channels: 40 AM / FM
  • Front speaker: Yes
  • Display type: LCD display
  • Display colors: Green / Orange
  • VOX Function: Yes
  • Squelch: ASQ (Automatiq Squelch Systeem) / Manual squelch /
  • Hi/Lo power: Yes
  • Scan function: Yes
  • Memory channels: Yes
  • External speaker socket: Yes
  • S-meter: Yes
  • Din mount: Yes
  • CTCSS: Yes, 38 codes

Elektrische eigenschappen

  • Voltage: 13,8 Volt / 24 Volt /
  • Channel step: 10 kHz
  • Operating temperature: -10° to +55° C

Transmitter

  • Frequency allowance: ± 100 Hz
  • Modulation AM: from 85% to 90%
  • Modulation FM: 2.0 kHz

Receiver

  • AM sensitivity: 0.5 µV for 10 dB SINAD
  • FM sensitivity: 0.5 µV for 10 dB SINAD
  • Frequency response: 300 Hz - 3 kHz
  • Signal to noise ratio: 40 dB
  • Maximum audio power: 4 Watt
  • Internal speaker: 8 Ohm, round

Fysieke eigenschappen

  • Length: 188 mm
  • Height: 57 mm
  • Width: 118 mm
  • Weight: 1900 gram
  • Antenna connector: UHF (PL)
  • Mike connector: 6 pin microphone

In de verpakking

  • Transceiver: 1 pcs
  • Microphone: 1 pcs
  • Fixing screws: 1 set
  • Mounting bracket: 1 pcs
  • Power lead: 1 pcs
  • User Manual: English, German

Downloads
