Comet - CMX-200

Artikelnummer: 805200

Barcode: 4932273180829

The Comet CMX-200 is a high quality cross needle meter that can be used for 1.6 - 200 MHz, to measure Forward Power, Reflected Power and SWR. With a maximum PEP power handling of 3 kW on HF and 1 kW on VHF. PEP switch to select average power or SSB / PEP. The Comet CMX-200 has a large and illuminated display. Gold-plated inner core connectors.

Frequentie bereik: 1.6 - 200 MHz

Vandaag verstuurd - Stock: 1

€ 143,95 (118.97 excl. 21% BTW)

Elektrische eigenschappen

• Backlight display / meter: Yes
• Impedance: 50 Ohm
• Power range: 1.8 - 30 MHz: 30 / 300 / 3000 Watts, above 50 MHz: 30 / 300 / 1000 Watts
• Accuracy: ±10%
• Minimum Power for SWR: 6 Watts
• Insertion loss: 0.2 dB
• Testing function: SWR and Power (FWD and REF / AVG and PEP)
• Voltage: 13.8 Volt, for display lightning only
• Maximum continuous power handling 1.8 - 30 MHz: 2 kW
• Maximum continuous power handling above 50 MHz: 800 Watts

Fysieke eigenschappen

• Input connector: UHF (PL) female, gold-plated inner core
• Output connector: UHF (PL) female, gold-plated inner core
• Length: 120 mm
• Height: 80 mm
• Width: 105 mm
• Weight: 623 gram

In de verpakking

• Meter: Yes
• DC power cable: Yes
• Installation manual: English
