CRT - Electro UV V3

Artikelnummer: 600825

Fabrieksnummer: PM 000825

Barcode: 3140650006339

The CRT Electro UV V3 is a compact dual band radio for amateurs equipped with all important functions. Now with VOX function. The Micron V2 offers switchable output power 5 / 10 / 20 Watt in VHF and UHF.

Frequentie bereik: 144-146 MHz / 430-440 MHz

Niet op voorraad - Levertijd in overleg

€ 89,95 (74.34 excl. 21% BTW)

Features

Display: Yes, Large multi-function color TFT display
VOX function: Yes,
DTMF: Yes,
Modulation: FM (Wide/Narrow)
Working mode: UU / UV / VU / VV
Tone burst: 1000 Hz / 1450 Hz / 1750 Hz / 2100 Hz
Dual watch: Yes
Time out Timer: Yes
CTCSS / DCS: Yes
CTCSS / DCS scan: Yes
Scan: Yes
External speaker socket: Yes
Yes, by computer: Yes, by computer

Elektrische eigenschappen

Frequency step: 2.5 kHz / 5 kHz / 6.25 kHz / 10 kHz / 12.5 kHz / 20 kHz / 25 kHz / 30 kHz / 50 kHz /
Channels: 500
Operating temperature: -20℃ to +60℃

Transmitter

Power output (Watts): 20 / 10 / 5 Watt
Audio distortion: ≤5%
Frequency stability: ±2.5 PPM
Type of modulation:
Hum & noise:
Audio response:

Receiver

Frequency stability: ±2.5 PPM
Audio response:
Adjacent channel selectivity:

Fysieke eigenschappen

Length: 124 mm
Height: 36 mm
Width: 101 mm
Weight: 450 gram
Antenna connector: UHF (PL)
Mike connector: RJ45 connector

In de verpakking

Transceiver: Yes
Microphone: Yes
Mounting bracket: Yes
DC power cable: Yes
Installation manual: English, French
