K-PO - CX-201 UHF (PL)

Artikelnummer: 905004

Barcode: 8718375100981

The K-PO CX-201 UHF (PL) is a 2 way antenna switch with a UHF (PL) female input connector and 2x UHF (PL) female output connectors.

Frequentie bereik: Up to 600 MHz

Vandaag verstuurd

€ 29,95 (24.75 excl. 21% BTW)

Elektrische eigenschappen

• Power continues: Max 1 kW
• VSWR: Less than 1.2:1
• Impedance: 50 Ohm
• Insertion loss: Less than 0.2 dB
• Isolation: Better than 50 dB

Fysieke eigenschappen

• Connector(s) type in: UHF (PL) female
• Connector(s) type out: UHF (PL) female
• Length: 90 mm
• Height: 40 mm
• Width: 80 mm
• Weight: 350 gram
