K-PO - Panther V2 K-PO - Panther V2 K-PO - Panther V2 K-PO - Panther V2 K-PO - Panther V2

K-PO - Panther V2

Artikelnummer: 2500
Fabrieksnummer: 2500
Barcode: 8718375101056

The K-PO Panther V2 is a professional handheld CB radio that comes pre-programmed with all the European channels and has its own Lithium-Ion battery pack, allowing many more hours of talk-time. It has all the features you would expect from a modern hand-held CB radio.

Improvements

  • Improved audio/speaker
  • Can be used with a new optional battery eliminator with antenna adapter, 12/24 volt
Frequentie bereik: 26.965 - 27.405 MHz
Niet op voorraad - Levertijd in overleg
€ 144,95 (119.79 excl. 21% BTW)

Features

  • Modulation: AM / FM
  • Multi-bands: Yes
  • Output power: 1-4 Watt
  • Channels: 40 AM / FM
  • Display type: Backlight
  • Display colors: Green
  • Squelch: Automatic squelch
  • Keypad lock: Yes
  • Hi/Lo power: Yes
  • Scan function: Yes
  • Memory channels: Yes
  • External speaker socket: Yes
  • S-meter: Yes
  • Dual watch: Yes
  • Roger beep: Yes
  • Socket for external microphone: Yes (2,5 / 3,5 mm mono)

Elektrische eigenschappen

  • Voltage: 7,4 Volt
  • Channel step: 10 kHz
  • Operating temperature: -20° to +55° C
  • Frequency control: PLL synthesizer
  • Frequency tolerance: ± 0.005%

Transmitter

  • Spurious emissions: -55 dB
  • Carrier suppression: -55 dB
  • Audio frequency response: 300 Hz - 2.5 kHz
  • Modulation AM: 100%
  • Modulation FM: ± 2 kHz

Receiver

  • AM sensitivity: <1.0 µV for 10 dB
  • FM sensitivity: <0.2 µV for 12 dB
  • Adjacent channel selectivity: > -55 dB
  • Maximum audio power: 1 Watt
  • Internal speaker: 8 Ohm, round
  • Squelch: Adjustable 6 Levels
  • Automatic Gain Control (AGC) Figure Of Merit: 100 mV for 10 dB Change in Audio Output.
  • Image rejection ratio: > -65 dB

Fysieke eigenschappen

  • Length: 35 mm
  • Height: 120 mm
  • Width: 120 mm
  • Weight: 250 gram (Including battery)
  • Antenna connector: TNC
  • Accessory connector: 2 pin Standard Icom (S)

In de verpakking

  • Transceiver: 1 pcs
  • Microphone: No
  • User Manual: English
  • Antenna: 1 pcs
  • Plug-in charger: 1 pcs
