K-PO - SPA 8230

Artikelnummer: 1484

This variable speed fan cool switching mode is designed for radio application . Its low profile and small footprint housing fit well in place with a host of radio receivers in a tight spot . It has constant current over load , floating ground and Output Over Voltage Protection. The SPA-8230 can be used for equipment till 23A continuous and 25A short.

Niet op voorraad - Levertijd in overleg

€ 129,95 (107.4 excl. 21% BTW)

Elektrische eigenschappen

• Input voltage: 230 Volt / 50 Hz /
• Output voltage: 13.8 Volt
• Adjustable output voltage: 13.3-14.5 Volt
• Continuous load: 23A
• Peak load: 25A
• Ripple voltage: ≤100mVp-p
• Fan: Yes
• Short circuit protection: Yes
• Overload protection: Yes
• Rated output power: 345W
• Cooling method: Fan cool (0 to full speed)

Fysieke eigenschappen

• Length: 181 mm
• Height: 63 mm
• Width: 190 mm
• Weight: 1700 gram

In de verpakking

• Power supply: Yes
• AC cord: Yes
• User manual: English

Downloads

• Informatieblad: User Manual SPA 8230 1
