Maas - SPS-8250

Artikelnummer: 8250

The Maas SPS-8250 is a power high power switching mode and has 2 analog meters. They are suitable for a wide range of uses, such as radio equipment. The power supply has a variable output from 3 to 15 Volt. The SPS-8250 can be used for equipment till 25A continuous.

Vandaag verstuurd - Stock: 2

€ 179,95 (148.72 excl. 21% BTW)

Elektrische eigenschappen

• Input voltage: 230 Volt / 50-60 Hz /
• Output voltage: 13.8 Volt
• Adjustable output voltage: 3-15 Volt
• Continuous load: 25A
• Ripple voltage: ≤50mVp-p
• Display indicator: Voltage / ampère
• Background light: Yes
• Fan: Yes
• Short circuit protection: Yes
• Overload protection: Yes
• Rated output power: 375W
• Cooling method: Thermostatic control fan

Fysieke eigenschappen

• Length: 220 mm
• Height: 110 mm
• Width: 220 mm
• Weight: 2700 gram

In de verpakking

• Power supply: Yes
• AC cord: Yes
• User manual: English

Downloads

• Informatieblad: User manual
