Proxel - SX-40

Artikelnummer: 101040

The Proxel SX-40 is a compact SWR and Power meter. Featuring cross needle design for measuring SWR and output power simultaneously. Compact size makes it very useful for testing mobiles as well as base station installation.

Frequentie bereik: 140 - 525 MHz

Volgende werkdag verstuurd - Stock: 8

€ 61,94 (51.19 excl. 21% BTW)

Elektrische eigenschappen

• Backlight display / meter: Yes
• Impedance: 50 Ohm
• Power range: 15 / 150 Watts
• Accuracy: ± 10%
• Minimum Power for SWR: 1 Watt
• Testing function: SWR and Power (FWD and REF)
• Voltage: 13.8 Volt, for display lightning only

Fysieke eigenschappen

• Input connector: UHF (PL) female
• Output connector: UHF (PL) female
• Length: 95 mm
• Height: 87 mm
• Width: 85 mm
• Weight: 280 gram

In de verpakking

• Meter: Yes
• DC power cable: Yes
• Installation manual: English
