RM - BLA 600

Artikelnummer: 50200026

Barcode: 5056109224156

The BLA 600 is a wideband compact linear amplifier for the HF bands and 6m, from 1.8 to 54 MHz.

*Protection circuits are not 100% guaranteed. To prevent damage to your amplifier always check your VSWR after changing bands, no hot switching, no excessive input power etc.

Frequentie bereik: 1.8-54 MHz

Niet op voorraad - Levertijd in overleg

€ 3.141,10 (2595.95 excl. 21% BTW)

Elektrische eigenschappen

• Input power (Watts): 1 - 40 AM-FM-SSB-CW
• Max output power (Watts): 500 AM-FM
• Max output power SSB (Watts): 500 (PEP)
• Max input SWR: <1.5:1 VSWR (160-6m)
• Fuse: 5 x 20mm F LBC 250V (Fast Blow)
• Inversion polarity protection: Yes
• Electronic switch: Yes
• LCD display: Yes
• Gain: Typical 14 dB +/- 1 dB (80-10m)
• Active device: NXP / Freescale MRFE6VP5600H (50V)
• Output harmonic / spurious distortion: HF >-45dB 6m >-60dBc
• PTT input: Close to ground TX, Open Circuit RX, (Suitable for Open Drain / Collector / Relay switching). Output +5V S/C current <15mA in TX.
• ALC output: Negative going voltage, (0 to –10V) (adjustable).
• PA current: 27 A (max)

Fysieke eigenschappen

• Input connector: UHF (PL) female
• Output connector: UHF (PL) female
• Length: 430 mm
• Height: 142 mm
• Width: 324 mm
• Weight: 21.500 gram
