RM - KL 200P

Artikelnummer: 1774

The RM KL 200P is an linear amplifier with inversion polarity protection and antenna pre-amplifier. The max. output power off the amplifier is 100 Watts AM-FM and 200 Watts SSB (PEP).

Frequentie bereik: 25-30 MHz

Vandaag verstuurd

€ 119,95 (99.13 excl. 21% BTW)

Elektrische eigenschappen

• Input power (Watts): 1-5 AM-FM / 2-10 SSB - CW
• Max output power (Watts): 100 AM-FM
• Max output power SSB (Watts): 200 (PEP)
• Impedance: 50 Ohm
• Max input SWR: 1.1 - 1.5
• Fuse: 12 A
• Inversion polarity protection: Yes
• Electronic switch: Yes
• Pre-amplifier: Yes
• Cooling fans: No
• Input energy/power: 8-11 A
• Antenna pre-amplifier: 26 dB

Fysieke eigenschappen

• Input connector: UHF (PL) female
• Output connector: UHF (PL) female
• Length: 109 mm
• Height: 35 mm
• Width: 125 mm
• Weight: 305 gram
• Color: Red or Blue

In de verpakking

• Amplifier: Yes
• DC power cord: Yes
• Installation manual: English
