RM - KL 703

Artikelnummer: 1794

Barcode: 000000001816

The RM KL 703 is an linear amplifier with inversion polarity protection. The max. output power off the amplifier is 500 Watts AM-FM-SSB (max).

*Protection circuits are not 100% guaranteed. To prevent damage to your amplifier always check your VSWR after changing bands, no hot switching,no excessive input power etc.

Frequentie bereik: 25-30 MHz

Volgende werkdag verstuurd - Stock: 6

€ 644,95 (533.02 excl. 21% BTW)

Elektrische eigenschappen

• Input power (Watts): 1-35 AM-FM-SSB-CW
• Max output power (Watts): 500 AM-FM
• Max output power SSB (Watts): 500 (PEP)
• Impedance: 50 Ohm
• Max input SWR: 1.1-1.5:1
• Fuse: 4x 15 A (auto fuse)
• Inversion polarity protection: Yes
• Electronic switch: Yes
• Pre-amplifier: Yes
• Cooling fans: 2
• Output power level: 3
• Input energy/power: 50 A
• Antenna pre-amplifier: 26 dB
• Transistor: 16x RM3 Mosfet
• Max output SWR: 2.5:1
• Max bypass power (amplifier off): 50 Watts (max)

Fysieke eigenschappen

• Input connector: UHF (PL) female
• Output connector: UHF (PL) female
• Length: 240 mm
• Height: 85 mm
• Width: 420 mm
• Weight: 4200 gram
• Color: Black

In de verpakking

• Amplifier: Yes
• Installation manual: English

Downloads

• Informatieblad: KL703 English Manual watermarked
