Sirio - AS 145 N

Artikelnummer: 220140523

Fabrieksnummer: 2201405.23

Barcode: 8056182113948

The AS 145 N antenna is a mobile antenna with N-PL mount and N cable.

Frequentie bereik: 27 - 28.5 MHz

Niet op voorraad - Levertijd in overleg

€ 31,94 (26.4 excl. 21% BTW)

Elektrische eigenschappen

• Electrical type: Base loaded
• VSWR: ≤ 1.2
• Bandwidth: 1240 kHz (110 channels) ≤ 2.0
• Power continues: 150 Watts (CW)
• Power peak: 450 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 4 meter / RG 58

Fysieke eigenschappen

• Materials: Copper, brass, stainless steel 17/7 PH, nylon
• Height: 1400 mm
• Weight: 200 gram
• Mounting type: Thru-hole

In de verpakking

• Antenna: Yes
• Radio connector: Not included, optional
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English, Italian

Downloads

• Informatieblad: Id 008 05 06 2014 as series
