Sirio - Cruiser VHF

Artikelnummer: 230152083

Fabrieksnummer: 2301520.83

156 - 163 MHz marine antenna working on VHF marine band without Ground Plane. The fiberglass radiator allow a perfect protection against the worst sea weather and is DC-grounded in order to avoid stray R.F. currents and their discharges. All its metallic components are made of chromed brass. It is supplied with M8" nylon marine mount and 5 meters white coaxial cable. In the mentioned range of frequencies adjustments are not required.

Frequentie bereik: 154 - 162.6 MHz

Vandaag verstuurd - Stock: 4

€ 89,95 (74.34 excl. 21% BTW)

Elektrische eigenschappen

• Electrical type: 1/2 λ base loaded
• Gain: 0 dBd, 2.15 dBi
• VSWR: 158 ≤ 1.2
• Bandwidth: 154 - 162.5 MHz ≤ 2.0
• Power continues: 100 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 5 meter / White RG 58

Fysieke eigenschappen

• Materials: Chromed brass, Fiberglass, Nylon
• Height: 1100 mm
• Weight: 680 gram
• Mounting type: Deck mount

In de verpakking

• Antenna: Yes
• Radio connector: UHF-male
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English

Downloads

• Informatieblad: Id 269 19 03 2018 cruiser vhf
