Sirio - CX 900 C N-f

Artikelnummer: 852
Fabrieksnummer: 2106601.00

UHF antennas for base station service made of high quality materials to get the best performance and the maximun efficiency. They are completely manufactured with aluminium tubes and thermoplastic UV stabilized for its great robustness and supplied with a solid steel bracket for an easy and safe installation. They are DC-grounded for a perfect protection against the discharges and no tuning is required. Simple and strong, they are particularly recommended for a professional use.

Frequentie bereik: 880 - 960 MHz
Volgende werkdag verstuurd - Stock: 8
€ 39,95 (33.02 excl. 21% BTW)

Elektrische eigenschappen

  • Electrical type: 3/4 λ coaxial J-pole
  • Gain: 0 dBd, 2.15 dBi
  • VSWR: TX: 880 - 915 MHz ≤ 1.8 / RX: 825 - 960 MHz: ≤ 2.8
  • Power continues: 100 Watts (CW)
  • Impedance: 50 Ohm
  • Polarization: Linear vertical

Fysieke eigenschappen

  • Materials: Aluminium, brass, galvanized steel, zamak
  • Mast Ø: 35 - 42 mm
  • Max wind resistance: 180 km/h
  • Height: 370 mm
  • Weight: 470 gram
  • Mounting type: On mast
  • Antenna connector: N-female

In de verpakking

  • Antenna: Yes
  • Mounting parts: Yes
  • Installation manual: English

Downloads
