Sirio - GP 430 LB-N

Artikelnummer: 210370100

Fabrieksnummer: 2103701.00/N

Barcode: 8056182113283

1/4 λ wide-band antenna for base station service covering the frequency range of 380-480 MHz. It as been developed according to the most modern technologies to assure a perfect protection against the worst atmospheric climates and to get the best performance. It is entirely made of aluminium to assure strength and robustness and its radial whip is earthed.

Frequentie bereik: 380 - 480 MHz

Niet op voorraad - Levertijd in overleg

€ 89,95 (74.34 excl. 21% BTW)

Elektrische eigenschappen

• Electrical type: 1/4 λ ground plane
• Gain: 0 dBd, 2.15 dBi
• VSWR: ≤ 1.7
• Power continues: 300 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical

Fysieke eigenschappen

• Materials: Anodized aluminium, stainless steel, nylon
• Mast Ø: 36 - 40 mm
• Max wind resistance: 180 km/h
• Height: 295 mm
• Weight: 830 gram
• Mounting type: On mast
• Antenna connector: N-female 'Gold Plated' central pin

In de verpakking

• Antenna: Yes
• Mounting parts: Yes
• Installation manual: English

Downloads

• Informatieblad: Id 079 07 05 2012 GP 430
