Sirio - HP 7000

Artikelnummer: 221050505

Fabrieksnummer: 2210505.05

UHF radialless vehicular antenna working on 70 cm band. The very best materials have been used to guarantee the maximum strength and the best performance. The whip, made of 17/7 PH stainless steel, has an inclination system that allows the 90 tilting without using keys or tools. Also a particular attention has been paid to the UHF-male connector with a gold plated center pin, PTFE insulator and silicone rubber gasket for a perfect waterproofing.

Frequentie bereik: 426 - 442 MHz

Volgende werkdag verstuurd

€ 53,95 (44.59 excl. 21% BTW)

Elektrische eigenschappen

• Electrical type: 5/8 λ
• Gain: 2 dB
• VSWR: ≤ 1.2 on center frequency / ≤ 2.0 @ 426 - 442 MHz
• Power continues: 100 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical

Fysieke eigenschappen

• Materials: Chromed brass, stainless steel 17/7 PH, nylon
• Height: 435 mm
• Weight: 250 gram
• Mounting type: On UHF-female (PL) connector (not included)
• Antenna connector: UHF-male (PL)

In de verpakking

• Antenna: Yes
• Installation manual: English

Downloads

• Informatieblad: Id 102 18 06 2015 HP7000
