Sirio - Performer 5000 LED 3/8

Artikelnummer: 2005000
Fabrieksnummer: 2418505.03/LED

200 mm stainless steel shaft. Unique LED PCB that light up when transmitting. High power vehicular antenna working on 27 MHz or 10 meter band. Low loss coil, 2.5 mm copper wire.

Frequentie bereik: 27 - 30 MHz
Vandaag verstuurd
€ 62,94 (52.02 excl. 21% BTW)

Elektrische eigenschappen

  • Electrical type: Centre loaded
  • VSWR: ≤ 1.2
  • Bandwidth: 2600 kHz (230 channels) ≤ 2.0
  • Power continues: 1500 Watts (CW)
  • Power peak: 5000 Watts (CW) / duty cycle, 5 seconds on, 5 seconds off
  • Impedance: 50 Ohm
  • Polarization: Linear vertical

Fysieke eigenschappen

  • Materials: Copper, chromed brass, stainless steel 17/7 PH, thermoplastic UV
  • Height: 2080 mm
  • Weight: 480 gram
  • Mounting type: On 3/8 female (stud) mount

In de verpakking

  • Antenna: Yes
  • Installation manual: English, Italian

Downloads
