Sirio - SLP 4G-LTE Cable

Artikelnummer: 211200100
Fabrieksnummer: 2112001.00

New - Directional wide band log periodic antenna from 698 to 2700 MHz, no tuning required! Compact dimensions, high lineair gain, good SWR response. Made of aluminium and high quality materials, low weight. Vertical and horizontal polarization.

Frequentie bereik: 698 - 2700 MHz
Vandaag verstuurd - Stock: 6
€ 109,95 (90.87 excl. 21% BTW)

Elektrische eigenschappen

  • Electrical type: Log periodic
  • Gain: 9 - 11 dBi
  • VSWR: ≤ 1.2 - 1.8, see the product manual under downloads
  • Power continues: 10 Watts (CW)
  • Impedance: 50 Ohm
  • Polarization: Linear vertical / Linear horizontal /
  • Cable length: 50 cm / White low loss

Fysieke eigenschappen

  • Materials: Aluminium, galvanized steel, thermoplastic UV stabilized
  • Mast Ø: 25 - 42 mm
  • Max wind resistance: 130 km/h
  • Length: 850 mm
  • Height: 290 mm
  • Width: 50 mm
  • Weight: 830 mm
  • Mounting type: On mast
  • Tuning radius: 820 mm

In de verpakking

  • Antenna: Yes
  • Radio connector: SMA-male
  • Mounting parts: Yes
  • Antenna cable: Yes
  • Installation manual: English
