Sirio - SMP 24-33 Cable

Artikelnummer: 211130300

Fabrieksnummer: 2111303.00

Barcode: 8056182111999.

Very compact directional multi-band panel antenna for 2.3 - 2.7 and 3.3 - 3.8 GHz for 5G, WiFi 2.4 GHz and other bands, no tuning required.

Easy and quick installation on mast or wall.

Frequentie bereik: 2.3 - 2.7 MHz / 3.3 - 3.8 GHz

Niet op voorraad - Levertijd in overleg

€ 66,95 (55.33 excl. 21% BTW)

Elektrische eigenschappen

• Electrical type: Mini panel
• Gain: 2.3 - 2.7 GHz: 10 dBi / 3.3 - 3.8 GHz: 13 dBi
• VSWR: See the product manual under downloads
• Power continues: 6 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable length: 30 cm / White low loss

Fysieke eigenschappen

• Materials: Galvanized steel, Thermoplastic UV stabilized, PCB
• Mast Ø: 25 - 42 mm
• Max wind resistance: 180 km/h
• Length: 154 mm
• Height: 134 mm (170 mm including mounting base)
• Width: 46 mm (66 mm including mounting base)
• Weight: 420 gram
• Mounting type: On mast, on wall

In de verpakking

• Antenna: Yes
• Radio connector: SMA-male
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English

Downloads

• Informatieblad: Id 409 09 10 2019 smp 24 33
