Sirio - SMP-918-9 Cable

Artikelnummer: 21100300

Fabrieksnummer: 2111003.00

Directional multi-band base station antenna for indoor or outdoor use working on 880 - 960 MHz and 1.7 - 2.17 GHz conceived for GSM 900 & 1800, PCS 1.9 GHz, DECT and UMTS systems. The radiant element is made on a PCB and it is protected by a thermoplastic UV-stabilized radome to get the best performance for long periods of time. It’s supplied with bracket for an easy installation on the mast. With 30 cm low loss cable with SMA-male connector.

Frequentie bereik: 880 - 960 MHz / 1.71 - 2.17 GHz

Vandaag verstuurd - Stock: 9

€ 49,95 (41.28 excl. 21% BTW)

Elektrische eigenschappen

• Electrical type: Mini panel
• Gain: 9 dBi
• VSWR: See the product manual under downloads
• Power continues: 20 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 30 cm / White low loss

Fysieke eigenschappen

• Materials: Galvanized steel, thermoplastic UV stabilized, PCB
• Mast Ø: 25 - 42 mm
• Max wind resistance: 180 km/h
• Length: 154 mm
• Height: 134 mm (170 mm including mounting base)
• Width: 46 mm (66 mm including mounting base)
• Weight: 400 gram
• Mounting type: On mast, on wall

In de verpakking

• Antenna: Yes
• Radio connector: SMA-male
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English

Downloads

• Informatieblad: Id 318 09 03 2009
