Sirio - SO 868-915-2 N-f

Artikelnummer: 211192000

Fabrieksnummer: 2111920.00

Barcode: 8056182115973

New - Base station antennas conceived for ISM/LoRa system working on 868 - 870 MHz, no tuning required. Can be used for cryptomining (Helium Miner) too. The radiant colinear dipoles are made of PCB and protected by a fiberglass tube. With N female connector inIncluding the Sirio FT-5 bracket for wall or mast mount.

Frequentie bereik: 868 - 915 MHz

Niet op voorraad - Levertijd in overleg

€ 47,95 (39.63 excl. 21% BTW)

Elektrische eigenschappen

• Electrical type: 1/2 λ
• Gain: 0 dBd, 2.15 dBi
• VSWR: ≤ 1.5
• Power continues: 20 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical

Fysieke eigenschappen

• Materials: Chromed brass, galvanized steel, fiberglass, PCB
• Mast Ø: 35 - 45 mm
• Max wind resistance: 200 Km/h
• Height: 290 mm
• Weight: 235 gram
• Mounting type: On mast, on wall, thru hole
• Antenna connector: N-female
• Ingress Protection: IP 64

In de verpakking

• Antenna: Yes
• Mounting parts: Yes
• Installation manual: English

Downloads

• Informatieblad: Id 466 30 11 2021 SO 868 915 2
