Sirio - SPB-918-10 Cable

Artikelnummer: 211020300

Fabrieksnummer: 2110203.00

Multi-band base station antenna working on 880-960 and 1.7-2.17 GHz conceived for GSM 900& 1800, PCS 1.9GHz, DECT and UMTS systems. The radiant element is made on a PCB and it is protected by a UV-stabilized radome to get the best performance for long periods of time. It is supplied with an aluminium bracket for an easy installation on the mast. No tuning required.

Frequentie bereik: 880 - 960 MHz / 1.71 - 2.17 GHz

Vandaag verstuurd - Stock: 2

€ 65,95 (54.5 excl. 21% BTW)

Elektrische eigenschappen

• Electrical type: Panel
• Gain: 900 MHz: 7.3 dBd, 9.4 dBi / 1.8 GHz: 6.6 dBd, 8.7 dBi
• VSWR: 900 MHz ≤ 1.6 / 1.17 - 2.02 GHz ≤ 1.5 / 2.02 - 2.17 GHz ≤ 2.0
• Power continues: 20 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 30 cm / RG 58

Fysieke eigenschappen

• Materials: Aluminium, thermoplastic UV stabilized, PCB
• Mast Ø: 25 - 42 mm
• Max wind resistance: 160 km/h
• Length: 305 mm
• Height: 230 mm
• Width: 65 mm (without bracket)
• Weight: 1100 gram
• Mounting type: On mast

In de verpakking

• Antenna: Yes
• Radio connector: SMA-male
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English

Downloads

• Informatieblad: Id 297 21 07 2003
