Sirio - T3 27 FME

Artikelnummer: 200140

Fabrieksnummer: 2207015.01/FME

One of the most used antennas on trucks and agricultural machines. Tunable top screw with protective rubber cap and equipt with FME female connector.

Note: when the situation allows we recommend to use the new, improved and longer Sirio T4 series. Which will give a better performance in most situations.

Frequentie bereik: 26.9 - 27.5 MHz

Niet op voorraad - Levertijd in overleg

€ 32,95 (27.23 excl. 21% BTW)

Elektrische eigenschappen

• Electrical type: Logarithmic loaded
• VSWR: ≤ 1.2
• Bandwidth: 700 kHz (65 channels) ≤ 2.0
• Power continues: 20 Watts (CW)
• Power peak: 100 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 4 meter / RG 58

Fysieke eigenschappen

• Materials: Brass, stainless steel, nylon
• Height: 620 mm
• Weight: 400 gram
• Mounting type: Thru-hole
• Antenna connector: FME female

In de verpakking

• Antenna: Yes
• Radio connector: Not included, optional
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English, Italian

Downloads

• Informatieblad: Id 152 02 07 2008 t series
