Stabo - XM 3004E-R VOX

Artikelnummer: 30131

Fabrieksnummer: 30131

Barcode: 4010384301316

The Stabo XM 3004E-R VOX is a mobile CB radio device and can be used on 12 and 24 Volt. The XM 3004E has an adjustable VOX function (5 levels) that makes it possible to communicate handsfree with the optional Stabo VOX microphone. This versions is included an original din mount from Stabo.

Frequentie bereik: 26.965 - 27.405 MHz

Niet op voorraad - Levertijd in overleg

€ 313,95 (259.46 excl. 21% BTW)

Features

• Modulation: AM / FM
• Multi-bands: Yes
• Output power: 4 Watt
• Channels: 40 AM / FM
• Display type: LCD display
• Display colors: Green / Orange / Purple / Blue / Cyaan / Yellow / Clear Blue
• VOX Function: Yes
• Noise blanker: Yes
• Squelch: ASQ (Automatiq Squelch Systeem) / Manual squelch /
• Emergency channel: Yes
• Scan function: Yes
• Quick channel selection: Yes
• External speaker socket: Yes
• TOT (time out timer): Yes
• Din mount: Yes
• External VOX socket: Yes
• Roger Beep: Yes

Elektrische eigenschappen

• Voltage: 13,8 Volt / 24 Volt /
• Operating temperature: -10° to +55° C

Transmitter

• Audio frequency response: 300 Hz - 3 kHz
• Microphone sensitivity: <3 mV
• Frequency allowance: ± 600 Hz
• Drain: 13.2 Volt: 2 A max / 24 Volt: 2 A max

Receiver

• AM sensitivity: ≤ -107 dBm 20 dB SINAD
• FM sensitivity: ≤ -107 dBm 20 dB SINAD
• Frequency response: 300 Hz - 3 kHz
• Adjacent channel selectivity: 60 dB
• Maximum audio power: 2 Watt
• Internal speaker: 8 Ohm
• Squelch sensitivity: min. 0.2 μV
• Image rejection: 70 dB
• Drain: 300 mA nominal / 750 mA max.

Fysieke eigenschappen

• Length: 165 mm
• Height: 35 mm
• Width: 115 mm (without DIN-mount)
• Weight: 600 gram (without DIN-mount)
• Antenna connector: UHF (PL)
• Mike connector: 6 pin connector

In de verpakking

• Transceiver: 1 pcs
• Microphone: 1 pcs
• Fixing screws: 1 set
• Power lead: 1 pcs
• DIN mount: 1 pcs
• User manual: English, German, French, Polish,

Downloads

• Informatieblad: User manual stabo xm3004e VOX DE EN FR PL
