Team - PT-6200 VHF

Artikelnummer: 6201

Barcode: 4010507080265

The Team PT-6200 is a VHF transceiver suitable for 136-174 MHz. The PT-6200 will be delivered with a 1500 mAh Li-Ion battery pack.

Frequentie bereik: RX/TX: 136-174 MHz

Niet op voorraad - Levertijd in overleg

€ 59,96 (49.55 excl. 21% BTW)

Elektrische eigenschappen

• Frequency step: 5 kHz / 6.25 kHz /
• Channels: 16

Transmitter

• Power output (Watts): 5/1 Watts
• Modulation limit: F3E (FM)
• Antenna impedance: 50 Ohm
• Channel separation: Narrow: 12.5 KHz / wide: 25 KHz
• Deviation: Narrow: 2.5 KHz / wide: 5 KHz
• RX sensitivity: Narrow: 0.28 µV at 12.5 KHz / wide: 0.75 µV at 25 KHz
• Audio output power: 0.50 Watts at 8 Ohm with 10% THD

Fysieke eigenschappen

• Length: 56 mm
• Height: 120 mm
• Width: 35 mm
• Weight: 332 gram
• Antenna connector: SMA male

In de verpakking

• Transceiver: Yes
• Battery: Li-Ion 1500 mAh
• Charger: Desk charger with adapter and 12 V car charger
• Antenna: Yes
• Installation manual: English, Dutch, German
• Hand strap: Yes
• Belt clip: Yes
